Leva System Tilt module B10

Leva System Tilt module B10

Programma di proiettori fissi e orientabili per sorgenti LED Chip On Board integrate. Possibilità di montaggio: a incasso, rasato a scomparsa totale e con cornice di battuta, a soffitto e parete, a binario eurostandard 230V e all’interno sia dei profili Lucifero’s Minifile e File 2 che nei relativi Container. Corpo apparecchio in estruso di alluminio verniciato. Gruppi ottici completi di… read more

Mandatory accessory according to the type of installation

Light source Code Power Color temp. Lumen CRI Lens Protocol Dim
LED LV093K.927S
10x2,2W
2700K
2150
>90
 Spot 20° On/Off L310xW75xH110+38 mm
LED LV093K.927SD
10x2,2W
2700K
2150
>90
 Spot 20° Dimmable Dali L310xW75xH110+38 mm
LED LV093K.927F
10x2,2W
2700K
2150
>90
 Flood 32° On/Off L310xW75xH110+38 mm
LED LV093K.927FD
10x2,2W
2700K
2150
>90
 Flood 32° Dimmable Dali L310xW75xH110+38 mm
LED LV093K.927W
10x2,2W
2700K
2150
>90
 Wide 50° On/Off L310xW75xH110+38 mm
LED LV093K.927WD
10x2,2W
2700K
2150
>90
 Wide 50° Dimmable Dali L310xW75xH110+38 mm
LED LV093K.930S
10x2,2W
3000K
2170
>90
 Spot 20° On/Off L310xW75xH110+38 mm
LED LV093K.930SD
10x2,2W
3000K
2170
>90
 Spot 20° Dimmable Dali L310xW75xH110+38 mm
LED LV093K.930F
10x2,2W
3000K
2170
>90
 Flood 32° On/Off L310xW75xH110+38 mm
LED LV093K.930FD
10x2,2W
3000K
2170
>90
 Flood 32° Dimmable Dali L310xW75xH110+38 mm
LED LV093K.930W
10x2,2W
3000K
2170
>90
 Wide 50° On/Off L310xW75xH110+38 mm
LED LV093K.930WD
10x2,2W
3000K
2170
>90
 Wide 50° Dimmable Dali L310xW75xH110+38 mm
LED LV093K.935S
10x2,2W
3500K
2360
>90
 Spot On/Off L310xW75xH110+38 mm
LED LV093K.935SD
10x2,2W
3500K
2360
>90
 Spot Dimmable Dali L310xW75xH110+38 mm
LED LV093K.935F
10x2,2W
3500K
2360
>90
 Flood On/Off L310xW75xH110+38 mm
LED LV093K.935FD
10x2,2W
3500K
2360
>90
 Flood Dimmable Dali L310xW75xH110+38 mm
LED LV093K.935W
10x2,2W
3500K
2360
>90
 Wide On/Off L310xW75xH110+38 mm
LED LV093K.935WD
10x2,2W
3500K
2360
>90
 Wide Dimmable Dali L310xW75xH110+38 mm
LED LV093K.940S
10x2,2W
4000K
2220
>90
 Spot 20° On/Off L310xW75xH110+38 mm
LED LV093K.940SD
10x2,2W
4000K
2220
>90
 Spot 20° Dimmable Dali L310xW75xH110+38 mm
LED LV093K.940F
10x2,2W
4000K
2220
>90
 Flood 32° On/Off L310xW75xH110+38 mm
LED LV093K.940FD
10x2,2W
4000K
2220
>90
 Flood 32° Dimmable Dali L310xW75xH110+38 mm
LED LV093K.940W
10x2,2W
4000K
2220
>90
 Wide 50° On/Off L310xW75xH110+38 mm
LED LV093K.940WD
10x2,2W
4000K
2220
>90
 Wide 50° Dimmable Dali L310xW75xH110+38 mm
